* Processor: Rockchip RV1126 Quad-core Cortex-A7@1.5GHz + RISC-V MCU @ 400 MHz
* RAM: 2GB
* Storage: 8GB
* Interfaces: 2x UART, CAN, RS485, USB2.0 Host/OTG, Gigabit Ethernet, MIPI DSI, 2x MIPI CSI, GPIO, SPI, SD, Audio I/O, etc.
* Operating system: Buildroot
* Board size: 162mm x 95mm
* Expansion Module: WiFi, Camera, 10.1" LCD


 Idea1126 SBC is a single board computer powered by Rockchip RV1126 SoC with a quad-core ARM Cortex-A7 and RISC-V MCU and a neural network acceleration with performance up to 2.0 TOPS. The RV1126 SBC comes with 2GB RAM and 8GB eMMC flash, equipped with Gigabit Ethernet, Wi-Fi, Bluetooth, RF315, MIPI DSI, as well as 2x MIPI CSI that supports 4Kp30 and one 1080p30 simultaneous.
Quad-core RV1126 AI SoC, combined with 4K-resolution stacked CMOS image sensor, PIR, Photovaristor and IR/White LED, make Idea1126 SBC can function efficiently under various lighting conditions as smart door lock solution.
